Collector 1" with 7 otv Thermal

Details

Stainless steel collector for 7 bends with a distance between them of 50 mm. Valves and flow meters from 0 to 5 liters per minute on each circuit for precise hydraulic regulation of the collector circuits. Temperature control valves on the return manifold. The flow meters on the feed pipe have the function of fully locking the loop and are designed for adjustment. Connection: external euroconus 3/4" (for contours) and internal 1" (collector) thread.
Thermoregulating valves on the return manifold, with the possibility of replacing the manual control cap with a servo (thread M30 x 1.5). The maximum operating pressure is 10 bar, the maximum operating temperature is 90 °C.

Brand
Termica

Number of outputs / pcs
7

Diameter
1"

Length / mm
440

Max. operating temperature
90

Max. pressure / bar
6
