Cabinet built-in metal 744mm SRV-3 Stout

Details

The Stout distribution built-in cabinet allows you to place all the necessary equipment for the distribution of heating and water supply systems in an orderly manner.
For the convenience of connecting pipelines, there is a perforation in the side walls of the housing.
The body material is galvanized steel.
The front panel is painted with a powder coating with a preliminary application of a phosphate film, which makes the case more resistant to corrosion.
The connection of the pipeline takes place in any convenient place, it is enough to remove the segments with perforations in the side walls.
Universal fasteners inside the STOUT allow you to distribute the equipment in the most ergonomic way.
Height adjustment up to 90 mm (extendable legs).
Depth 125 mm, depth adjustment up to 70 mm (extendable frame).
The legs are equipped with holes for fixing to the floor.
Folding latches will help to fix the cabinet in the wall niche.
Internal lock.

Code, dimensions

SCC-0002-000045 - 670x125x496mm
SCC-0002-000067 - 670x125x596mm
SCC-0002-000810 - 670x125x746mm
SCC-0002-001112 - 670x125x896mm
