Ball valve 16x 1/2" BP butterfly

Details

(VT.342.N) Reduced ball valve (reduced passage) for use in engineering systems and technological installations based on metal polymer pipes at temperatures from -15 to +110 ° C and operating pressure up to 10 bar. Non-repairable, with a minimum resource of 4 thousand cycles. Equipped with a butterfly-type handle made of aluminum alloy with epoxy painting. The connection to the metal–polymer pipeline is crimped, one–sided; the thread of the second branch pipe is internal. It is not intended for use on risers, main pipelines and sections of systems in which bending forces transmitted to the crane body may occur.

Intended for use as part of engineering systems and technological installations based on metal polymer pipes

Valtec brand

Code VT.342.N.1604

Operating temperature from -15 to +110 °C

Maximum
working pressure 10 bar

The minimum resource is 4 thousand cycles

Crimp connection, one-way

Material: Brass

Connection thread: Internal

Connection size: 1/2"

Pipeline diameter (mm): 16

Type of handle "butterfly"

Manufacturer's country: Italy
